| Product number | Load capacity | Wheel width | Hub length | Total height | Plate dimensions | Bolt hole spacing | Bolt hole diameter | Axle bore | Offset | Unit weight | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
WJ-75 | 80kg(780N) | 32mm | 36mm | 103mm | 82×82mm | 63×63mm | 9.5mm | 10mm | 22mm | 0.58kg |
 |
WJ-100 | 130kg(1270N) | 35mm | 43mm | 144mm | 95×95mm | 71×71mm | 11mm | 12mm | 35mm | 1.11kg |
 |
WJ-130 | 180kg(1760N) | 42mm | 53mm | 177mm | 108×108mm | 80×80mm | 11.5mm | 20mm | 40mm | 1.97kg |
 |
WJ-150 | 200kg(1960N) | 45mm | 56mm | 198mm | 120×120mm | 90×90mm | 11.5mm | 20mm | 45mm | 2.31kg |
 |
WJ-180 | 230kg(2250N) | 45mm | 56mm | 240mm | 140×140mm | 112×112mm | 11.5mm | 20mm | 58mm | 3.51kg |
 |
WJ-200 | 250kg(2450N) | 45mm | 56mm | 250mm | 140×140mm | 112×112mm | 11.5mm | 20mm | 58mm | 3.74kg |
 |
WJ-250 | 330kg(3230N) | 50mm | 90mm | 305mm | 160×160mm | 125×125mm | 14mm | 25mm | 71mm | 6.93kg |
 |
WJ-300 | 350kg(3430N) | 50mm | 109mm | 374mm | 175×175mm | 140×140mm | 14mm | 25mm | 71mm | 9.09kg |
 |
SSTJ-100 | 130kg(1270N) | 35mm | 43mm | 144mm | 95×95mm | 71×71mm | 11mm | 12mm | 35mm | 1.09kg |
 |
SSTJ-130 | 180kg(1760N) | 42mm | 53mm | 177mm | 108×108mm | 80×80mm | 11.5mm | 20mm | 40mm | 1.94kg |
